Level 4 Cut Resistant HPPE Fabric for Glove Liner & Car Mirror Cover | UHMWPE Woven Safety Protection Material
- STYLE NAME: Anti-cut fabric
- COMPOSITION: 100%Para-aramid fiber
- CONSTRUCTION: Twill woven
- APPLICATION: Bedding, Mattress, Outdoor-Awning, Outdoor-Industry
- CODE: WH501-05
- WEIGHT: 380gsm(+/-5%)
-
WIDTH: 160cm(+/-5cm)
-
Abrasion-Resistant, Chemical-Resistant, Tear-Resistant, Anti-UV
- Overview
- Recommended Products
Model Number: WH501-05
Width: 160cm
Weight: 380gsm
Content: HPPE+fiberglass+polyester+nylon
Feature: Cut Resistant
Standard: ANSI CUT A4, EN388: 2003 2542, Reach SVHC 201 PASS
Function: Provides high-level cut and resistance for car side mirror protective cover, protective gloves, etc.
Technical Sheet
Item |
Unit |
Technical Specification |
Test Standard |
Thickness |
mm |
0.83 |
JIS1096-2010 |
Basis Weight |
g/m² |
400±20 |
GB/T 4669-2008 |
Tensile Strength (Warp) |
N / 25mm |
3934.314 |
GB/T3923-2013 |
Tensile Strength (Weft) |
N / 25mm |
2453.988 |
GB/T3923-2013 |
Elongation at Break (Warp) |
% |
61 |
GB/T3923-2013 |
Elongation at Break (Weft) |
% |
13 |
GB/T3923-2013 |
Tearing Strength (Trapezoid) |
N |
1726 |
GB/T 19978-2005 |
Width |
mm |
1600 |
GB/T21665-2008 |
Product Details
Product Applications
